FREE GATE RELAY ASSEMBLY CLOCKWISE (COUNTER CLOCKWISE)
PART
NO.
A365-00085-OO00 (A365-()()()86-()OOO)
EJECT HOLE ASSEMBLY - PARTS LIST
PART NO. A331-00035-0000
ORDER BY PART NUMBER ONLY
ITEM
PART NO.
DESCRIPTION
1
A360-00012-0000 CORE PLUG ASSY.
2
A360-00211-0000 COIL
&
TUBING ASSY.
103E-00002-0015 IN4004GP 400V 1A DIODE
3
0017-00104-0073 SPRING WASHER .515"
1.0. ,
.875" 0.0.
&
.013" TH.
4
0360-00313-00XF SOLENOID BRACKET
5
0360-00714-00XF PLUNGER
6
A360-00018-00XF BRACKET
&
SPRING HOOK ASSY.
7
0017-00007-0089 ROLL PIN
8
0017-00007-0043 COTTER PIN
9
0010-00270-0000 EXTENSION SPRING
10
A360-00019-00XF BALL KICKER ASSY.
11
0360-00708-00XF SHAFT
12
0017-00100-0110 RING RER .188" OIA. (3 REQ'D)
13
0010-00275-0230 EXTENSION SPRING
14
A360-0002l-00XF MOUNTING BRACKET ASSY.
I
,
1.39
1.33
