EJECT HOLE (SAUCER) ASSEMBLY
PART NO.A331-00035-0000
FREE GATE RELAY ASSEMBLY ClOCKWISE (COUNTER CLOCKWISE)
PARTNO. A365-00085-0000 (A365-00086-0000)
ORDER BY PART NUMBER ONLY
ITEM
PART NO.
DESCRIPTION
1
0390-00702-00XF i:BAL GATE SHAFT
I
2
0017-00100-0120 RING RER .250 DIA.
3 ' A365-00084-0000 'BASE PLATE
&
BEARING ASSY.
A390-00031-0000 HUB
&
ROLL PIN ASSY. (ITEMS 4
&
5)
4
0390-00703-00XF HUB
5
0017-00007-0066 ROLL PIN 3/32 X 10
AE34-00023-0000 "G" RELAY
&
COIL ASSY. (ITEM 6 THRU 13)
6
0017-00042-0627 ACTUATOR: SWITCH RELAY
7
A390-00030-0000 GATE BALL ACTUATOR
8
AE34-00022-0000 SWITCH: FREE GATE RELAY ASSY.
9
0020-00243-0000 SPRING PLATE
10
A390-00029-0000 COIL (2 LUG)
&
POLE PIECE ASSY.
,
11
0390-00107-00XF SPRING RETAINER
I
12
0010-00135-0200 COMPRESSION SPRING
13
0390-00106-00XF RELAY FRAME
I
I
I
1.32
1.40
