DROP TARGET ASSEMBLY (3 POS.)
PART NO. AE52 - 00013 - 0000
liS-
,RELAY ASSEMBLY
&
COIL - PARTS LIST
PART INO. AEI4-00030-0000
ORDER BY PART NUMBER ONLY
ITEM
PART NO.
DESCRIPTION
1
0017-00042-0627 ACTUATOR: SWITCH RELAY
-
2
A365-000B1-0000 ARMATURE RELAY ASSY.
3
AE34-00022-0000 SWITCH: FRE GATE RELAY ASSY.
4
0020-00243-0000 SPRING PLATE
5
AE14-00046-0000 COIL
&
POlf PIECE ASSEMBLY (2 LUG)
6
o
390-00107-00XF SPRING RETAINER
7
0010-00135-0200 COMPRESSION SPRING
8
I
0390-00106-00XF ;RElAY fRAME
1.27
1.46
