Page 33 - 1987_COMMON_PARTS_ASPIRE

KICKER POST ASSEMBLY
PART NO. AE3S-00012-0000
1.49
DROP TARGET ASSY.: 3-IN-LINE (YELLOW) - PARTS LISTPART NO. AE94-00033-0000
ORDER BY PART NurmER ONLY
ITEM PART NO. DESCRIPTION
AE94-00039-0000 TARGET & LINK ASSY.: YELLOW (3 REQ'D.) (INCLUDES ITEMS 1 THRU 5)
1 A967-00032-0000 YOKE, BRACKET & STUD ASSY.
2 0011-00005-00XF STUD: PIVOT
3 0017-00042-0466 TARGET: DROP; YELLOW
4 0360-00117 -OOXF LINK: DROP-TARGET
5 0017-00100-0117 RING: KLl .250" (2 REQ'O. )
6 A360-00014-0000 CORE-PLUG & BRACKET ASSY.
7 AB42-00045-0000 COIL & TUBING ASSY. 2-LUG
103E-00002-0015 1N4004 GP 400V lA DIODE
8 A967-00066-0000 SWITCH & DIODE ASSY. (3 REQ'D. )
A360-00062-0000 SWITCH ASSY.
9 OA44-00105-00XF PLATE: SIDE-FRAME
10 OA44-00107-00XF PLATE: TOP-FRAME/RIGHT (3 IN-LINE)
11 OA44-00108-00XF RESET BAR (SIDE-BY-SIDE DROP TARGET)
12 OA44-00700-00XF SHAFT: 3 IN-LINE TARGET
13 0010-00275-0353 SPRING: EXTENSION (3 REQ'D.)
14 0010-00275-0350 SPRING: EXTENSION
15 0017-00042-0429 NYLINER: SNAP-IN; COIL (2 REQ'D. )
16 0017 -00100-0117 RING: KL1 .250" (6 REQ'D.)
17 0360-00118-0000 LINK: DROP TARGET (2 REQ'D.)
18 0360-00122-00XF BRACKET: COIL
19 0360-00717-00XF PLUNGER
20 0360-00721-00XF PIN: LINK (2 REQ'O. )
21 0370-00145-03XF PLATE: BOTTOM - STATIONARY L=4 - 15/16"
22 0370-00146-03XF PLATE: BOTTOM - ADJUSTABLE L=3 - 15/16"
1.25a
