DROP TARGET ASSEMBLY: 3 IN-LINE (YELLOW)
PART NO. AE94-00033-0000
••
~~
.. .
.' ...t "
~i~
1.24
KICKER-POST ASSEMBLY - PARTS LISTPART NO. AE35-00012-0000
ORDER BY PART NUMBER oNLY
ITEM PART NO. DESCRIPTION
1 A967-00011-0000 CORE - PLUG & BRACKET ASSY.
2 A967-00046-0000 COIL & TUBING ASSY. (2 LUGS)
103E-00002-0015 IN4004GP 400V lA DIODE GLASS
3 0010-00274-0212 SPRING: COMPRESSION
4 0017-00042-0430 NYLINER: SNAP-IN, COIL
5 0017-00042-0725 POST: KICKER, NYLON
6 0017 -00100-0115 RING RER .438 5144-43 ST (2 REQ 1D. )
7 0017-00104-0073 SPRING WASHER •513" 1.0., .875" 0.0. & .013'1TH •
8 0360-00318-00XF BRACKET: COIL
9 0967-00130-00XF BRKT.: MOUNTING SLINGSHOT
10 0967-00701-00XF PLUNGER
11 0017-00041-0637 RUBBER RING: 5/1611
