SLINGSHOT KICKER ASSEMBLY
A967-00059-0000 DROP TARGET ASSEMBLY 3 IN-lINE "/MEMORY - PARTS LIST
PART NO. AE47-00029-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. I DESCRIPTION
I
I AE47-00034-0000 MEt~ORY - COIL ASSY. (INCLUDES ITEMS 1 THRU 6)
I
I 1 AE47-'D0013-00XF PLUNGER & STRIKER ASSY. (3 REQ1 D.)
I
2 0360-00122-00XF COIL BRACKET
3 AE47-00037-0000 COIL & TUBING ASSY. (2 LUGS) (3 REQ'D)
103E-00002-0015 IN4004 GP 400V lA DIODE (6 REQ'D.)
4 OE47 ..•00103-01XF BRKT.: MEt·1ORYCOIL
-
5 0010-00274-0206 COMPRESSION SPRING
6 0017-00041-0636 BUMPER: PLUG. BLACK, RUBBER (3 REQ'D.)
AE47 ...00035-0000 3-IN-LINE TARGET ASSY. (INCLUDES ITEMS 7 THRU 30)
7 A360 ..•00014-0000 CORE PLUG & BRKT. ASSY.
8 AE47-00037-0000 COIL & TUBING ASSY. (3 LUGS)
,
I 103E-00002-0015 ]N4004 6P 400V lA DIODE ,
9 A370-00086-0000 SWITCH & DIODE ASSY. (3 REQ'O.)
A370-00085-0000 SWITCH ASSY.
10 OA44-00108-00XF RESET BAR
11 OA.44-00700-00XF SHAFT
12 OE47-00102-00XF FRAME: TOP PLATE, LEFT
13 0010-00275-0350 EXTENSION SPRING
14 0010-00279-0314 EXTENSION SPRING (3 REQ'D.)
15 0017-00042-0429 NYLINER: SNAP IN COIL (2 REQ1D.)
16 0020-00202-0000 SWITCH PLATE (3 REQ'D.)
17 0360-00118-0000 LIMK (2 REQ 'o. )
1---.
AE47-0004S-0000 3-TARGET & LINK ASSY. (INCLUDES ITEMS 18 THRU 22)
18 I AE47-00016-0000 TARGET ASSY. (3 REQ'O.)
-
1.52 1.22a
