DROP TARGET ASSEMBLY 3 IN-LINE WIMEMORY
PART NO. AE47-00029~OOOO
1.21
SlINGSHOT KICKER ASSY.
PART NO. A967-00059-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION.
1 A967-00011-0000 CORE PLUG & BRACKET ASSY.
2 A967-00046-0000 COIL (2 LUG) & TUBING ASSY. ,
I 103E-00002-0015 I IN4004GP 400V lA DIODE
3 0017-00104-0073 SPRING WASHER .515" 1.0 •• •875" 0.0. & .013" TH.
4 0360-00318-00XF COIL BRACKET
5 0010-00274-0212 COMPRESSION SPRING
-
6 0967-00701- 0XF PLUNGER
7 0017-00100-0115 RING RER .438" DIA. (2 REQ'D)
8 0967-00901-0000 KICKER-ARM: SLINGSHOT
9 0017-00042-0430 NYLINER: SNAP-IN, COIL ,
10 0967-00130-00XF MOUNTING BRACKET: SLIN,GSHOT ,
1.53
