TOP MOUNTED KICKER (BAll RETURN) ASSEMBLY
PARTNO.A360-00234-OOOO
1.56
DROP TARGET ASSY.: 3 IN-LINE - PARTS LISTPART NO. AHOI-00016-0000
ORDER BY PART NUMBER ONLY
ITEM· PART NO. DESCRIPTION
1 AH01-00041-0000 TARGET W/HOT-STAMP ASSY.: 2X
0017-00042-0466 TARGET: DROP; YELLOW
2 AH01-00042-0000 TARGET W/HOT-STAMP ASSY.: 3X
0017-00042-0466 TARGET: DROP; YELLOW
3 AH01-00043-0000 TARGET W/HOT-STAMP ASSY.: 6X
0017-00042-0466 TARGET: DROP; YELLOW
4 A967-00032-0000 YOKE, BRACKET & STUD ASSY. (3 REQ'O.)
5 0011-00005-00XF STUD: PIVOT (3 REQ'D.)
6 0360-00117-00XF LINK: DROP TARGET (3 REQ'D.)
7 A360-00014-0000 CORE-PLUG & BRACKET ASSY.
8 AB42-00045-0000 COIL & TUBING ASSY. 2-LUG
103E-00002-0015 1N4004 GP 400V lA DIODE
9 A370-00086-0000 SWITCH & DIODE ASSY.: IN-LINE (3 REQ I D. )
A370-00085-0000 SWITCH ASSY.
10 OA44-00105-00XF PLATE: SIDE-FRAME
11 OE47-00102-00XF FRAME: TOP-PLATE (LEFT)
12 OA44-00108-00XF RESET BAR (SIDE-BY-SIDE DROP TARGET)
l.l9a
