DROP TARGET ASSEMBLY : 3 IN-LINE
PART NO. AH01 -00016-0000
1.18
TOP MOUNTED KICKER (BAll RETURN) ASSEMBLY - PARTS lISTPART NO. A360-00234-0000
ORDER BY PART HUMBER ONLY
ITEM PART NO. DESCRIPTION
1 A360-00013-0000 CORE PLUG ASSEMBLY
2 A360-00044-0000 COIL & TUBING ASSEMBLY (2 LUGS)
103E-00002-0015 IN4004GP 400V lA DIODE
3 0360-00901-0000 FISHPAPER INSULATOR
4 0010-00274-0189 COMPRESSION SPRING
A360-00278-0000 PLUNGER & LINK ASSY. (ITEMS 5, 6, & 7)
5 0360-00735-00XF PLUNGER
6 0017-00007-0073 ROLL PIN
7 0360-00941-0000 KICKER LINK
8 0017-00100-0116 RING RER .218" DIA, (2 REQ I D)
9 A360-00036-0000 KICKER ARM ASSY. (BALL RETURN)
10 0017-00042-0346 STRIKER RING
11 A360-00037-0000 BASE PLATE ASSY.
12 0017-00007-0124 COTTER PIN
