Page 22 - 1987_COMMON_PARTS_ASPIRE

DROP TARGET ASSEMBLY SINGLE IN-LINE W/MEMORY - PARTS LIST. COUTIO.
PART NO. AE47 -00023-0000
ORDER BY PART NUMBER ONLY
BACK CABINET ASSY.- PARTS LIST
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION _.
23 OE47-00100-00XF BRKT.: PLUNGER LINK
24 OE47-00700-00XF PLUNGER
25 OE47-00101-00XF BRKT.: COIL MOU~TING
26 AE47-00039-0000 COIL & TUBING ASSY. (2 LUGS)
27 A9 67-00011-0000 CORE PLUG & BRKT. ASSY.
28 0017 -00 100-0117 RING KLI .250 (7 REQ'O.)
ITEM PART NO. DESCRIPTION
1 A365-00304-0000 DISPLAY & CONTROLLER CABLE ASSY.
2 A36S-00309-0000 LAMP SOCKET W/CONNECTOR & PINS ASSY.
3 A365-00317-0000 DUAL DISPLAY MODULE BOARD W/CLIPS ASSY. (2 REQ ID. )
B084-91851-HOOO DUAL DISPLAY MODULE BOARD ASSY.
0365-00174-00XF CLIP: DISPLAY (2 REQ'D.)
4 0365- 00317 -0000 BRKT: DISPLAY P.C. BOARD MTG.
5 0365-00153-0000 BRKT: P.C. BOARD SUPPORT (4 REQ'D.)
6 0365-00104 ...00XF GRILLE: VENT
7 0365-00960-0100 RETAINER: GLASS L=26-7/16
8 0365-00963-0000 FOIL: BACK-BOX: FLUORESCENT
9 0365-00105-00XF BRKT: PIVOT
10 0365-00114-00XF BRKT: PIVOT-OPEN
11 AH03-00013-0000 POWER MODULE & SPACER ASSY.
A084-91785-AH03 PROGRAMMED 6803 POWER MODULE (W/FUSES}(INCLUDES NEXT 3 ITEMS)
B084-91785-0000 6803 POWER MODULE (W/FUSES)
0017-00003-0169 FUSE: ABC 3AG SA 250V FAST-BLOW
0365-00952-0000 SHIELD: POWER SUPPLY
