Page 88 - 1968_BALLY PARTS CATALOG_ASPIRE

P.3384
STEPPING UNITS, FULL RESET
CO·28R·15
A.1766
SPRING
SEE NOTE A
P·3389
,-- --, M.254
STEP·UP ARM
SEE NOTE A
Operate Reset Plunger by hand unr iI Ratche t resets
to zero position, i .e . ,until resetting movemen t Stops .
Then operate Seep-up Plunger and, while holding
Step-up Plunger in , check to see that Reset Pawl rests
at base of rarche r-rcoth (point at which straight and
angular edge s of tooth meet) . If Reset Paw I is not at
base of tooth , adjus r .Spr.ing-Srop (P-3384) until Rat-
chet moves into position to permit Pawl properly ( 0
engage tooth , as described. Then check unit manual-
ly by operating Step-Up Plunger. After Reset Pawl
drops into position described abcve , Step-up Arm
should over -ride approximately 1/64 in. before being
CONTACT-PLATE WIPER ASSY.
(WIRED)
SEE NOTE A
SWITCH
SEE NOTE A
CORE-PLUG ASSY.
SEE NOTE A
STEP·UP COIL
SEE NOTE A
C-342
GUIDE-RING
P-1158-6
SPRING-WASHER
(Not Vi si bl e)
RATCHET
SEE NOTE A
stopped by Step-Up Arm Stop ("ear" formed In Base
Plate) . Bend Stop one way or another to reduce or in-
crease over-ride to approximately 1/64 in. Reset Pawl
sh ou Id then properly drop into base of tooth, without
binding , when Re set Plunger is lightly operated (with-
out pushing Plunger all the way in).
NOTE A
If part number not listed in SPECIFIC PARTS DATA ,
commencing on page 8, order part by name, specifying
narn I" of un it, name of game_
WHEN ORDERING 'PART, SPECIFY PART NO. AND NAME OF GAME
85
