Page 87 - 1968_BALLY PARTS CATALOG_ASPIRE

STEPPING UNITS, CONTINUOUS
Match (0-9) Units with Bell
CaNT A.CT -PLA. IE
(WIRED) WIPER A.SSY
SEE NOTE A
COIL
SEE NOTE A
SPRING
SEE NOTE A
P-405-14
SP-401
A-2ass P-l1S8-6
SPRING-WASHER
(Not Vi si ble)
TO SILENCE BELL
STEP-UP ARM
SEE NOTE A
PLUNGER
SEE NOTE A
Loosen Bell by turn ing in counter-clockwise direction.
Lower Bell to bottom of slot in m 0 U f) t if) g-bracker.
Tighten Bell by turning in clockwise direction.
ADJUSTMENTS
NOTE A
See adjus tment instructions, page 83.
If Part Number not listed in SPECIFIC PARTS
DA T A, commencing on page 8, order part by
name, specifying name of game, name of unir,
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
