A-17540 Universal Power Interface Assembly
j
SIDE VIEW
Item Part No.
Description
Item Part No.
Description
1.
01-12293
Power Control Chassis Box.
15.
20-9682-1
Boot w/9-32 Dia. Hole
2.
4406-01128-00 Nut, #6-32 KEPS
16.
5102-13864-00 Line Filter wllEC Connector
3.
01-12294
Switch Mounting Plate Assembly
17.
01-12292
Line Filter Chassis Box
4.
5642-13935-00 Power Switch
18.
H-17992
Jumper Cable Neutral Sw/1 FC
5.
01-12299
Insulator, Terminal Strip
19.
4004-01003-05 Mach. Screw, #4-40 x 5/16"
6.
RM-21-06
#18 Vinyl Fgls
20.
H-18050
Jumper Cable, Transformer Prog.
7.
5822-13865-00 Terminal Strip 3-CKT 2-Mtg.
21.
16-9667
Label Convenience Rcp!. Rating
8.
5733-12869-00 Fuse Holder Panel
22.
H-17543
Hot Jumper Black Cable
9.
4408-01128-00 Nut, #8-32 KEPS
23.
H-17546
Jumper Interface Hot Black Cable
10.
5851-13867-00 Outlet-IEC Conn. 237 Socket
24.
H-17545
Jumper Switch/Fuse Black Cable
11.
03-8712
Strain Relief Bushing
25.
H-17542
Ground Jumper
12.
5016-12978-00 Thermistor 8A, 2.5R25
26.
5797-13940-01 Jumper Cable
13.
4008-01017-10 Mach. Screw, 8-32 x 5/8" P-PH-S
27.
01-10623
Insulator, Thermistor
14.
03-7520-3
Ty-Wrap Nylon
SIDE VIEW
o
-
o
:ULJJ
la
I
!
[J~g
0 0
o
o
o
TOP VIEW
2-27
