A-18232
Back Panel Assembly
Item Part Number
Description
Item Part Number
Description
1.
11-831-50031
Wood Back Panel
8.
4106-01115-20 Sh. Metal Screw, #6 x 1/2"
2.
01-11679
Ramp Mounting Bracket
9.
4106-01114-08 TCS #6 x 1/2"
3.
31-1925-9
Playfield Plastic
10.
03-7655-4
Clip Harness 1/4"
4.
A-17713
Lamp Assembly
• 11.
31-1928-10
Decal, Right
5.
4008-01168-12 Mach. Screw, 8-32 x 3/4"
• 12.
31-1928-9
Decal, Left
6.
4408-011 68-12 Nut #8-32
13.
01-12569
Gusset, Back Panel
7.
03-8022-1
Standoff, 9/16"
14.
03-8063-6
Bulb Sleeve, Yellow
• Not available for individual sale. Order Decal Set 31-1928.
2-26
