A-18222 Mini-Playfield Assembly
4
Item Part Number
Description
Item Part Number
Description
1.
36-50031-1
Hard Coat Mini-Playfield
9.
5070-09054-00 Diode 1N4004
2.
20-9247
Coil Magnet
10.
4002-01105-06 Mach. Screw, 2-56 x 3/8"
3.
A-18157
Magnet Bracket & Pole Piece
11.
4808-01175-08
E-P
#8 x 1/2 IND.
PL-HWH
4.
12-7195.1
Wire Ball Guide
12.
03-7655-4
Cable Clamp, 1/4"
5.
5647-12693-59 Switch
13.
20-9672
Wave Spring Washer
6.
A-18226
Switch Ball Guide Assembly
14.
01-13063
Shield, Mini-Playfield Switch
7.
H-18205
Switch Cable
15.
03-7520-2
Tie Wrap, Nylon 3-7/8"
8.
17-1116-2
Jumper Wire Cut, 2"
16.
03-9189-3
Mylar
