A..17741 Goalie Unit Assembly
FRONT VIEW
SIDE VIEW
BACK VIEW
Item Part
No.
Description
Item Part
No.
Description
1.
14-7997
Motor
14.
4700-00033-00 Flatwasher, 17/64 x 3/4 x 15ga.
2.
4008-01 003-12 Mach. Screw, 8-32 x 3/4"
15.
4008-01083-08 Set Screw, #8-32 x 1/2'
3.
A-17780.1
Mtr. Bracket Assembly
16.
10-362
Spring
4.
A-17744
Crank Assembly
17.
A-17779
Target Switch Assembly
5.
A-17782.1
Drive Assembly
18.
20-8712-25
"E" Ring, 1/4" Shaft
6.
A-17743
Target Assembly
19.
H-18204
Opto Cable Assembly
7.
01-12333.1
Goalie Opto Bracket
20.
4008-01168-06 Mach. Screw, #8-32 x 3/8"
8.
03-8523
Insulator, 3/4 x 1-1/4"
21,
4408-01119-01 Nut #8-32 ESN
9.
03-9134
Goalie Plastic
22.
4005-01003-12 Mach. Screw, #5-40 x 3/4"
10.
H-18214-1
SWitch Cable Assembly
23.
01-12823
Nut Plate
11.
A-16909
Photo Transistor Assembly
24.
03-7520-2
Tie Wrap
12.
A-16908
LED Assembly
25. *31-1924-7
Decal
13.
4106-01013-06 Sh. Metal Screw, #6 x 3/8"
26.
H-18600-4
Cable
* Not available for individual sale. Order Decal Set 31-1924.
2-20
