A-15849-R-2
Flipper Assembly
Item Part No.
Description
Item Part No.
Description
1.
B-13104-R
Flipper Base Assembly, Right
18.
A-15848-R
Crank Link Assembly, Right
2.
SW-1A-194
Switch Assembly
a)
A-17050-R
Flipper Crank Assembly, Right
3.
4701-00002-00 Lockwasher, #6 Split
b)
A-15847
Flipper Link Assembly
4.
4105-01019-10 Sh. Metal Screw, #5 x 5/8"
c)
02-4676
Link Spacer Bushing
5.
4008-01079-05 Mach. Screw, 8-32 x 5/16"
d)
4010-01086-14 Cap Screw, 10-32 x 7/8"
6.
4701-00003-00 Lockwasher #8 Split
e)
4700-00023-00 Flatwasher, 5/8 x 13/64 x 16ga.
7.
01-9375
Switch Mounting Bracket
f)
4701-00004-00 Lockwasher #10 Split
8.
20-6516
Speednut, Tinnerman
g)
4410-01132-00 Nut, 10-32 ESN
9.
4010-01066-06 Cap Screw, 10-32 x 3/8"
19.
23-6577
Bumper Plug, 5/8"
10. 4701-00004-00 Lockwasher #10 Split
20.
03-7568
Flipper Bushing
11. A-12390
Flipper Stop Assembly
12. FL-11629
Flipper Coil, Blue
a) 03-7066-5
Coil Tubing
Associated Parts:
13. 01-7695
Solenoid Bracket
14. 4006-01017-04 Mach. Screw, 6-32 x 1/4"
21.
23-6695
Flipper Rubber Ring, Red
15. 10-364
Spring
22.
20-9250-5
Flipper & Shaft, White
16. 4006-01005-06 Mach. Screw, 6-32 x 3/8"
17.
4406-01117-00 Nut, 6-32 Hex
Flipper Notes ...
1. Each Flipper Assembly is mounted beneath the playfield, in conjuction with the Plastic Flipper & Shaft, and Flipper
Rubber on the upper side of the playfield.
2. With the flipper, in the non-activated position, the E.O.S. Switch contacts must have a gap of .062 (±.015) inch. When
flipper is activated switch must close.
3. Any adjustment of the E.O.S. switch must be made at a minimum distance of 0.25 inch from the switch body.
4. Longer blade of E.O.S. switch must be made straight. Gap adjustment is done by adjusting shorter blade.
5. All moving elements of the assembly must operate freely without any evidence of binding.
6. Apply Loctite™ 245 when reataching screws to the Flipper Stop Assembly, the Solenoid Bracket, and the Flipper Bushing.
2-17
