T.15 Eject Hole Test
This test is used to test and adjust the eject holes in the game.
All devices will kick out balls in this test.
The top "assist" eject hole will operate the goalie, and use the same method used in multi-ball
play to shoot the ball to the left of the goalie.
Each of the eject hole solenoids may also be energized manually as follows:
Left Eject:
Top (assist) Eject:
Right Eject:
Press Left Flipper Button
Press Start Button
Press Right Flipper Button
When operated manually, the solenoid will fire for an extra-long time to allow you to grab hold of
the actuator for manual adjustment.
Note that a very slight bend will affect the kick-out as
follows:
To kick further right:
To kick further left:
Bend actuator slightly left.
Bend actuator slightly right.
It is recommended that the side eject holes be aligned such that the ball just clears the slingshots
and lands on the highest part of the corresponding flipper.
It is recommended that the top eject when firing on its own should shoot the ball when the goalie
is in the rightmost position and should pass on the left side of the goalie without touching the
target. If it kicks at a different time, then check the Right Goalie Opto using the Goalie Test. If it
kicks at the correct time, but does not go into the goal, then a small adjustment to the actuator
must be made.
1-20
