A-15573 Big Foot Mech. Assembly
Item Part Number
Description
1.
01-10746
Base Bracket
2.
401 0-01 006-04 Mach. Screw, 10-32 x
1/4
P-PH-S
3.
14-7973
Gear Motor
4.
02-4564
Standoff
5.
A-15668
2-Switch Opto PC Board (See p.2-18)
6.
03-8698
Actuator Opto Switch
7.
02-4666
Mounting Block
8.
A-16243
Diverter Shaft Assembly
9.
23-6577
Bumper Plug
10.
4700-00030-00
Flatwasher,
17/64
x
1/2
x 15ga.
.,
11.
10-399
Compression Spring
12.
02-3407-2
Coil Plunger,
2-1/8"
13.
AE-26-1200
Coil Assembly
14.
01-10892
Mounting Bracket
15.
4700-00104-00
Flatwasher,
23/64
x
112
x 16ga.
16.
12-6227
Hairpin Clip
17.
20-8712-31
"E"-Ring,
5/16"
Shaft
18.
4008-01 003-05 Mach. Screw, 8-32 x
5/16
PH-PHD
19.
03-7066
Coil Tubing
20.
4008-01076-04
Set Screw, 6-32 x
1/4
SH-CP
21.
4700-00060-00
Flatwasher, 7/32 x
1/2
x 16ga.
22.
4408-01128-00
Nut 8-32 KEPS
23.
03-8085
Armature Link
24.
20-8716-5
Roll Pin,
1/8
x
7/16"
25.
A-16046
Head Assembly
26.
A-16047
Body & Log Assembly
- -
27.
4006-01017-06
Mach. Screw, 6-32 x
3/8
P-PH SEMS
28.
4106-01033-08B Sh.- Metal Screw, #6 x 112 P-TH-BLK
WHITE WATER 2-28
