A-15769 Ball Popper & Opto Assembly
•.
1------;
12
6 )-----+---1
Item Part Number
Description
Item Part "Jumber
Description
1.
4106-01019-06 Sh. Metal Screw, #6 x 3/8"
9.
4106-01152-06 Sh. Metal Scew, #6-32 x 3/8"
2.
4008-01017-04 Mach. Screw, 8-32 x 1/4"
10.
03-8506-1
Opto Mounting Base, White
3.
AE-23-800
Coil Assembly
11. 03-7067-5
Coil Tubing
«
4.
10-135
Spring
12. A-15914
Bracket, Ball Popper\'
5.
02-4668
Armature Assembly
13.
23-6420
Rubber Grommet
6.
01-9794
Mounting Bracket
14.
A-14316
Photo Transistor Assembly
7.
03-8506
Opto Mounting Base, Black
15. A-14315
LED Assembly
8.
03-8561
Ball Popper Cup
16. 4104-01001-06 Sh. Metal Screw, #4 x 3/8"
~
WHITE WATER 2-27
