MAINTENANCE INFORMATION
LUBRICATION
The two main lubrication polnts of the Ball Release mechanism are the pivots for the arm. The
mechanisms of other playfield devices are somewhat similar to the Ball Release device, and have the same
lubrication requirements. A medium viscosity oil (switch target grease) is satisfactory for these devices.
Because of the functional design (arm-actuated via solenoid plunger operation), the pivot points of the
Left and Right Kickers ("Slingshots") all require lubrication as a regular servicing procedure.
Lubrication to ensure proper operation also applies to the target blades of the Drop Targets. MBI
Instrument Grease, also known as Drop Target Switch Lubricant, with a Williams' part number of EI165, is a
recommended lubricant.
•
SWITCH CONTACTS
Playfield Switches
For proper game operation, switch contacts should be free of dust, dirt, contamination, and corrosion.
Blade switch contacts are plated to resist corrosion. Cleaning blade switch contacts requires gentle
closing of the contacts on a clean business card or piece of paper, and then pulling the paper about 2
inches, which should restore the clean contact surface. Adjust the switch contacts to a 1/16-inch gap.
Flipper Switches
This game uses the new Fliptronic II Electronic Flipper System.
The End-of-Stroke switches are
NORMALLY OPEN. The switch should close when the flipper is energized. All E.O.S. switches and
flipper button cabinet switches are gold flashed computer grade leaf switches. Only low computer current
is carried through these switches. DO NOT FILE or abrasively clean these switches! DO NOT REPLACE
these switches with the old style tungsten high current type switches as intermittent operation could
occur. Note: Unlike the old style of flipper, an E.O.S. switch failure does not harm the flipper. The game
notifies the operator of the switch being mis-adjusted in the test report, but continues to play. The E.O.S.
switches are a means by which the new electronic flippers feel and play with all of the subtleties of the old
flippers.
CLEANING
Good game action and extended playfield life are the results of regular playfield cleaning. During each
collection stop, the playfield glass should be removed and thoroughly cleaned and the playfield should be
wiped off with a clean, lint-free cloth. The game balls should be cleaned and inspected for any chips,
nicks, or pits. Replace any damaged balls to prevent playfield damage.
Regular, more extensive, playfield cleaning is recommended. However, avoid excessive use of water and
caustic or abrasive cleaners because they tend to damage the playfield surface. Playfield wax (or any
carnauba based wax), or polish may be used sparingly, to prevent a buildup on the playfield surface. Do
not use cleaners containing petroleum distillates on any pJayfieldplastics because they may dissolve the
plastic material or damage the artwork.
CHANGING BACKBOX DOME BULBS
The bulbs located on the top of the backbox can be changed without removing the dome. Turn off
power to the game. Remove the three tamper proof screws from the front of the dome, (the long arm key
needed to do this is located in the cashbox). Carefully lift the dome enough to get your hand under it.
Pull the burnt-out bulb out of its socket and replace it with a new one. Replace the tamper proof screws
and turn the game back on.
NOTE:
Replace with #194 bulbs only. Part Number 24-8831.
WHITE WATER
1-38
