GAME CONTROL LOCATIONS
Cabinet Switches
The On-Off Switch is on the bottom of the cabinet near the right front leg.
The Start Button is a pushbutton to the left of the coin door on the cabinet exterior. Press the Start
button to begin a game, or during the diagnostic mode, to ask for HELP.
Coin Door Buttons
The operator controls all game adjustments, obtains bookkeeping information, and diagnoses problems,
using only four pushbutton switches mounted on the inside of the coin door. The Coin Door Buttons
have two modes of operation Normal Function and Test Function.
Normal Function
..
The Service Credits button puts credits on the game that are not included in any of the game audits.
The Volume Up (+)button raises the sound level of the game. Press and hold the button until the
desired level is reached.
The Volume Down (-) button lowers the sound level of the game. Press and hold the button until the
desired level is reached. See Adjustment A.1 28 to shut sound Off completely.
The Begin Test button starts the Menu System Operation and changes the Coin Door Buttons from
Normal Function to Test Function.
Test Fynction
The Escape button allows you to get out of a menu selection or return to the Attract Mode.
The
llJll+)
button allows you to cycle forward through the menu selections or adjustment choices.
The Down (-) button allows you to cycle backward through the menu selections or adjustment
choices.
The .Erl1eLbuttonallows you to get into a menu selection or lock in an adjustment choice.
Holding the Enter button for five seconds, during the Attract Mode, resets the High
Scores.
Front Molding
WHITE WATER 1-5
