A-14039
Dot Matrix Controller Board
Interboard Wiring
•
J601
,.
'"
3D
J602
~:
J606
n
J604
J603l:=:Lj
...
J
I~
J601, 34-pln Ribbon Cable (data) Tolfrom J202; J903; J50S
J602, 26-pln Ribbon Cable (data) To/from J201
J603, 14-pln Ribbon Cable (data) To/from Dot Matrix Display/Driver
J604 -1 Orange (-125V) to Display/Driver pin 1
J604 - 2 Blue (-113V) to Display/Driver pin 2
J604 - 3 N/C
J604 - 4 Black (Grd) to Display/Driver pin 4
J604 - 5 Black (Grd) to Display/Driver pin 5
J604 - 6 Gray (+5V) to Display/Driver pin 6
J604 -7 Gray-Yellow (+12V) to Display/Driver pin 7
J604 - 8 Brown (+S2V) to Display/Driver pin 8
J605 -1 White (80VAC) from xformer secondary
J605 - 2 White (80VAC) from xformer secondary
J605 - 3 Violet (100VAC) from xformer secondary
J605 - 4 N/C
J605 - 5 Violet (100VAC) from xformer secondary
J606 - 1 Black (Grd) loop from J606-3
J606 - 2 N/C
J606 - 3 Black (Grd) from Power Driver Brd J117-3
J606 - 4 Gray (+5V) loop from JS06-5
J606 - 5 Gray (+5V) from Power Driver Brd J117-4
J606 - 6 Gray-Yellow (+12V) loop from JS06-7
J606 - 7 Gray-Yellow (+12V) from Power Driver Brd J117-2
WHITE WATER 3-42
