Power Driver Board Interboard Wiring Continued ...
J129 -1
Brown-Black (5019 drive) to backbox flashlamp
J129 - 2
N/C
J129 - 3
N/C
J129 - 4
N/C
J129 - 5
N/C
J130 -1
Violet-Brown (sol.
1
drive) to playfield coil
J130 • 2
Violet-Red (sol.
2
drive) to playfield coil
J130 - 3
N/C
J130 - 4
Violet-Orange (sol.
3
drive) to playfield coil
J130 - 5
Violet-Yellow (sol.
4
drive) to playfield coil
J130 - 6
Violet-Green (sol.
5
drive) to playfield coil
J130 - 7
Violet-Blue (sol.
6
drive) to playfield coil
J130 - 8
Violet-Black (sol.
7
drive) to backbox coil
J130 - 9
NlC
•
J131 -1
N/C
J131 - 2
N/C
J131 - 3
N/C
J131 - 4
N/C
J131 - 5
Violet-Gray (sol.
8
drive) to backbox flashlamps
J132 -1
N/C
J132 - 2
N/C
J132 - 3
N/C
J132 - 4
N/C
J132 - 5
N/C
J133 - 1
Red-Brown (lamp row
1)
to playfield lamps
J133 - 2
Red-Black (lamp row
2)
to playfield lamps
.J133 - 3
N/C
J133 - 4
Red-Orange (lamp row
3)
to playfield lamps
J133 - 5
Red-Yellow (lamp row
4)
to playfield lamps
J133 - 6
Red-Green (lamp row
5)
to playfield lamps
J133 -7
Red-Blue (lamp row
6)
to playfield lamps
J133 - 8
Red-Violet (lamp row
7)
to playfield lamps
J133 - 9
Red-Gray (lamp row
8)
to playfield lamps
J134 -1
NlC
J134 - 2
N/C
J134 - 3
N/C
J134·4
N/C
J134 - 5
N/C
J134 - 6
N/C
J134 -7
N/C
J134 - 8
N/C
J134 - 9
Red-Gray (lamp row
8)
to Coin Door Brd
J 1-2
J135 -1
N/C
J135 - 2
N/C
J135 - 3
NlC
J135 - 4
NlC
J135 - 5
NlC
J135·6
NlC
J135·7
NlC
J135·8
N/C
J135·9
NlC
J136·1
N/C
J136·2
N/C
J136·3
Yellow-Gray (lamp col.
8)
to cabinet lamp
J137 • 1
Yellow-Brown (lamp col.
1)
to playfield lamps
J137· 2
Yellow-Red (lamp col.
2)
to playfield lamps
J137.3
Yellow-Orange (lamp col.
3)
to playfield lamps
J137·4
Yellow-Black (lamp col.
4)
to playfield lamps
J137·5
Yellow-Green (lamp col.
5)
to playfield lamps
J137·6
Yellow-Blue (lamp col.
6)
to playfield lamps
J137·7
Yellow-Violet (lamp col.
7)
to playfield.lamps
J137·8
N/C
J137·9
Yellow-Gray (lamp col.
8)
to playfield lamps
J138·1
N/C
J138·2
N/C
J138·3
N/C
J138 - 4
N/C
J138 - 5
N/C
J138 - 6
N/C
J138·7
NlC
J138·8
NlC
J138·9
N/C
