A-14876-R-5
Flipper Assembly
11
Item Part Number
Description
Item Part Number
Description
1 A-14877-R
Flipper Base Assembly, Right
18 A-15848-R
Crank Link Assembly, Right
2 SW-1A-194
Switch Assembly
a) A-17050-R
Flipper Crank Assembly, Right
3
4701-00002-00
Lockwasher #6 Split
b) A-15847
Flipper Link Assembly
4 4105-01019-10
Sh. Metal Screw, #5 x 5/8"
c) 02-4676
Link Spacer Bushing
5 4008-01079-05
Mach. Screw, 8-32 x
5/16"
d) 4010-01086-14
Cap Screw, 10-32 x
7/8"
6 4701-00003-00
Lockwasher #8 Split
e) 4700-00023-00
Flat Washer, 5/8 x 13/64 x 16ga.
7 01-9375
Switch Mounting Bracket
f) 4701-00004-00
Lockwasher #10 Split
8 20-6516
Speednut, Tinnerman
g) 4410-01132-00
Nut 10-32 ESN
9 4010-01066-06
Cap Screw, 10-32 x 3/8"
19 23-6577
Bumper Plug, 5/8"
10 4701-00004-00
Lockwasher #10 Split
20 03-7568
Flipper Bushing
11 A-12390
Flipper Stop Assembly
12 FL-15411
Flipper Coil, Orange
13 01-7695
Solenoid Bracket
Associated Parts:
14 4006-01017 -04 Mach. Screw, 6-32 x 1/4"
(Not Shown)
15 10-364
Spring
16 4006-01005-06
Mach. Screw, 6-32 x
3/8"
21 23-6519-4
Flipper Rubber Ring, Red
17 4406-01117 -00 Nut 6-32 Hex.
22 20-10110-5
Flipper Bat w/Shaft
Flipper
Notes ...
1. Each Flipper Assembly
is
mounted beneath the playfield. in conjunction with the Plastic Flipper
&
Shaft, and Flipper Rubber on the upper side of the
playfield.
2. With the flipper, in the non-activated position, the Eo.S. Switch contacts must have a gap of
.062 (±.015)
inch. When flipper is activated switch must close.
3. Any adjustment of the Eo.S. switch must be made at a minimum distance of
0.25
inch from the switch body.
4. Longer blade of E.
0. S.
switch must be made straight. Gap adjustment is done by adjusting shorter blade.
5. All moving elements of the assembly must operate freely without any evidence of binding.
6. Apply Loctite
™
245
when reattaching screws to the Flipper Stop Assembly. the Solenoid Bracket. and the Flipper Bushing.
2-16
