A-20439
Shooter Lane Auto Kicker Assembly
Item Part Number
1 04-10210.3
2 04-10211.3
3 A-12390
4 4010-01066-06
5 4701-00004-00
6 AE-23-800
7 03-7066
8 01-8413
9 10-128
10 A-15847
11 4700-00104-00
12 12-6227
13 4006-01003-05
14 01-8600
15 5647-12693-62
16 4002-01105-08
17 H-16437
18 5070-09054-00
19 H-19523
Description
Kicker Crank Assembly
Coil Mounting Bracket
Flipper Stop Bracket Assembly
Cap Screw, #10 x 3/8"
Lock Washer #10 Split
Coil Assembly
Coil Tubing
Coil Mounting Bracket
Spring
Flipper Link Assembly
Flat Washer, 23/64 x 1/2 x 16ga.
Hairpin Clip
Mach. Screw, 6-32 x 5/16"
Insulator
Mini-Micro Switch
Mach. Screw, #2-56 x 1/2"
Cable
Diode1 N4004
Cable
2-15
