Left And Right Divert Mechanisms
1. To service divertor mechanism· Left ramp divertor.
a. Unplug mechanism from main wire harness .
.. b. Remove tension spring carefully. (See Fig. 10)
TENSION
SPRING
Fig. 10
c. Unscrew set-screws (2 places) using a
3/32
Hex Allen wrench, until divertor shaft can drop
.
.
through top of playfield. (See Fig. 11)
DIVERTOR SHAFT
TO PLAYFIELD
Fig.
11
1-61
