3.
Lubrication points
a. Periodically (every 2 to 3 months depending on usage) wipe clean the square shaft of the
kicker assembly with an absorbent rag or towel, carefully removing as much grease, grime
and dirt as possible. Re-apply a small amount of Teflon grease, using a cotton swab or similar
applicator, to all four sides of the square shaft. Compress the kicker shaft several time to work
in the grease. (See Fig. 8)
DAB OF GREASE
ALL FOUR (4)
SIDES OF SQUARE
SHAFT
COMPRESSED
POSITION
DAB OF GREASE
ALL FOUR (4)
SIDES OF SQUARE
SHAFT
Fig. 8
b. Do Not lubricate the four bronze bushing that are found on the sliding carriage of the kicker
assembly. They are oil impregnated and will not need to be lubricated. If lubricated,
contamination may occur and subsequently destroy the bushings. (See Fig. 9)
c. Do Not lubricate the rack or the pinion gear. They are made of a plastic material that does not
require any lubrication. If the rack or pinion are lubricated they may become contaminated and
subsequently be destroyed resulting in the failure of the mechanism. (See Fig. 9)
DO NOT LUBRICATE
RACK OR PINION
DO NOT LUBRICATE BRONZE
BUSHINGS!!! (4 PLACES)
Fig. 9
4. Miscellaneous standard parts and mechanisms
a. All other items on the mini-playfield are standard parts (i.e, lamps, targets, optos, 4-bank drop
target). To be serviced as regular standard mechanisms.
