A-18954
Divertor Mechanism Assembly
(Left Side)
Item Part Number
1 A-18956-2
2 01-13116
3 03-7066
4 AE-25-1000
5 A-18957
6
4408-01119-00
.•7
5070-09054-00
8
20-8716-5
9 02-5135
10 A-18983
11 401
o-on
86-04
12 10-320
13 H-19704
.•Only item location shown.
Description
Associated Parts:
left Bracket, Divertor Mech.
Bracket - large Coil
Coil Tubing,
1-3/4"
Coil Assembly
Coil Stop Bracket Assembly, large
Nut, 8-32 ESNA
Diode 1N4004, 1.0A.
Roll Pin,
1/8
x
7/16"
Armature
Crank Arm Assembly
Set Screw, 10-32 x
1/4"
Extension Spring
Divertor Cable
A-19638-1
Knife
&
Diverter Assy.
20-8712-25
"E"-Ring,
1/4'
Shaft
4700-00027-00 FW,
1/4
x
1/2
x 21ga.
2-24
