A-14756 Captain B.Zarr Assembly
Item Part Number
Description
Item Part Number
Description
1.
A-14759
Bracket & Motor Assy.
h) 4010-01006-04 Mach. Screw, 10-32x 1/4
a) 01-10275
Motor Mounting Bracket
j)
4700-00011-00 Flatwasher, 11/64 x 7/16
b) 14-7968
Motor,12V
k) 03-7655-4
Harness Clip
c) 03-8580
Opto Switch Actuator
2.
A-15008
Head Mech. Assy. (See p. 2.31)
d) 4408-01119-00 Nut, 8-32 ESN
3.
4008-01076-06 Set Screw, #-32 x 3/8
e) 02-4564
Standoff, #10-32
4.
H-14955
Motor Cable
f) A-14766
Motor Opto Switch
5.
03-7520-2
Ty-Wrap
g) 01-10276
Stop Plate
PARTY ZONE
2.30
