A-12742-20004 WPC CPU Board
I
Item
!:Jatt ~l.imber
>
·•.•.•.O~slgnilt()r
.. .:/. Oesc:flptl()rf<
5010-09034-00
R14-R22, R27-R42, R86,
Resistor, 10Kn,
1/4w, 5%
R90, R94,R98
2 5010-09085-00
R1,R2,R4,R93,R96,R97
Resistor, 1.5Kn,
1/4w, 5%
3 5010-09314-00
R52, R54, R56, R58, R60,
Resistor, 1.2Kn,
1/4w, 5%
R62, R64,R66, R75-R82
4 5010-09358-00
R3, R43-R51, R53, R55, R57,
Resistor, 1Kn,
1/4w, 5%
R59, R61, R63, R65, R67-R74,
R84
5 5010-09416-00
R5-R8, R12, R13, R87-R89
Resistor, 4700,
1/4w, 5%
6 5010-09534-00
W1, W4, W7, W13- W18
Resistor, 00
7 5010-10258-00
R95, R99
Resistor, .01j.lfdO,
1/4w, 5%
8 5010-10989-00
R92
Resistor, 470KO,
1/4w, 5%
9 5010-12104-00
R91
Resistor, 22j.lfd,
1/4w, 5%
10 5019-09362-00
SIP 1
SIP, 9R, 10-pin, 4.7Kn, 5%
11 5040-08986-00
C31
Capacitor, 100j.lfd, 10v (±20%)
12 5043-08980-00
B
Capacitor, .01j.lfd, 50v, (+80, -20%)
13 5043-09030-00
C27
Capacitor, 0.047j.lfd, 50v (±20%)
14 5043-09065-00
C3 - C26
Capacitor, 470pfd, 50v (±20%)
15 5043-09491-00
C2, C29, C30, C34
Capacitor, 22pfd, 1KV, (±10%)
16 5043-09492-00
C28
Capacitor, 100pfd, SOv, (±10%)
17 5043-09845-00
C32,C33
Capacitor, 1KP, SOv, (±20%)
18 5070-08919-00
02 - D18
Diode, 1N4148, 150MA
19 5070-09266-00
D1, D25
Diode, 1N5817, 1.0A.
20 5160-10269-00
Q1
Transistor, 2N3904, NPN
21 5162-12422-00
U20
IC, ULN, 2803A
22 5281-09308-00
U3
IC, 74LS245, Octal Bus Trncv
23 5281-09486-00
U14
IC, 74LS374, 8D F/F
24 5281-09851-00
U5
IC, 74LS14, SMTITRG
25 5281-09867-00
U1, U2, U7
IC, Octal Buffer, 74LS244
26 5281-10182-00
U11, U12, U13, U15
IC, 74LS240 Driver
27 5284-12651-00
U21
IC,4584
28 5340-12278-00
US
S/RAM2064
29 5370-12272-00
U16 - U19
IC, LM339, Quad. Comp
30 5370-12687-00
U10
MC, 34064 Reset Chip
31 5520-10438-00
X2
Crystal, 8.0MHz.
32 5520-12084-00
X1
Crystal 32.768 KHz
33 5551-09822-00
L1
ILN, 4.7 UH 3A
34 5671-090 19-00
D19 - D21
DSPLLED RED
35 5700-08985-00
U4
Socket, IC 40P, .6"
36 5700-12088-00
U6
Socket, IC 32P, .6"
37 5700-12424-00
U9
Socket, 84 Pin PLCC
38 5764-12431-00
PC Board
39 5791-10850-00
J201,J204
Connector, 26-pin Header Str Sq.
40 5791-10862-07
J210
Connector, 7-pin Header SIr Sq.
41 5791-12461-08
J212
Connector, 8-pin Header Str Sq.
42 5791-12461-09
J206 - J209
Connector, 9-pin Header Sq. pin
43 5791-12461-12
J205
Connector, 12-pin Header Sq. pin
44 5791-12516-00
J202, J211
34 Hen 2x17 STR
45 5881-09021-00
B1 - B3
Battery Holder" AA·
46 5048-11033-00
C50
Capacitor,0.022j.lf,
10v
47 16-8850-358
PCB Label
48 A-5343-20004
U6
Game PROM Assembly
49 5410-12426-00
U9
WPC-89 ASIC
50 5400-10320-00
U4
IC MPU 68B09E
51 5880
c
09022-00
B1 - B3
Battery, Alkaline, 1.51,1("AA")
