A-12738-20004 WPC Audio Board
(continued)
.... D8$crlptlon.
5370-12260-00
5370-12728-00
5370-12730-00
5370-12742-00
5371-12727-00
5432-12726-00
5460-12423-00
5460-12743-00
5520-09020-00
5521-10931-00
5551-09822-00
5700-08985-00
5700-09004-00
5700-09006-00
A-5343-20004-2
A-5343-20004-3
A-5343-20004-4
5700-12088-00
5705-12755-00
5731-08633-00
5733-12060-01
5766-12433-00
5791-10862-04
5791-10862-05
5791-10862-07
5791-12462-03
5791-12462-04
5791-12516-00
16-8850-359
U2
U1
U7,U8
U32
U19
U5
U4
U33
X1
OSC1
L1
U13
U10
U11
U14
U15
U18
IC, 3340 Elec Atten
IC, Audio Amp LM1875
IC, Op Amp TL084
IC, Op Amp TL082
DacAD7524
EE Prom Pot X9503
IC, LM7812
LM7809 T0-220
Crystal, 3.58 MHz.
Oscillator, 8.0 MHz.
Ind, 4.7UH 3.0A.
Socket, IC 40-pin, .6"
Socket, IC 24-pin, .6"
Socket, IC 16-pin, .3"
IC, Audio ROM
IC, Audio ROM
IC, Audio ROM
Socket, IC 32-pin (U14, U15, U18)
Heatsink 5299B-220
Fuse, 3A, S-B
Fuse Holder (F501, F502)
PCB-Sound 90
Connector, 4-pin Header Sq .. 156
Connector, 5-pin Header Sq .. 156
Connector, 7-pin Header Sq .. 156
Connector, 3-pin Header Sq .. 100
Connector, 4-pin Header Sq .. 100
34 Hen 2x17 STR
PCB Label
U1
F501,F502
J504,J505
J502
J501
J509
J508
J506
2.7
PARTY ZONE
