GAME OPERATION
&
CAUTION
After assembly and Installation at the site location,
this game must be plugged
Into a properly grounded outlet to prevent
shock hazard, and to assure proper
game operation.
DO NOT use a 'cheater'
plug to defeat the ground pin on the
line cord.
DO NOT cut off the ground pin.
--
~
,
POWERING UP.
With the coin door closed, plug the game in and switch it On, using the
On-Off Switch. In normal operation, Testing will show in the display as the game performs Start-
Up Tests. Once the Start-Up Tests have been successfully completed the last score is
displayed. Afterward, the game goes into the Attract Mode (playfield and backbox lamps
flashing, sounds heard, etc., if the operator does not change the Factory Setting).
Note:
After the game has been on location for a period of time, the Start-Up Tests may
contain messages concerning game problems. The section entitled 'Problem Analysis
Messages' contains more detail conceming messages displayed at each game turn-on.
Open the coin door and press the Begin Test Switch. The display shows the game name,
game number and game software revision. The message changes. The display shows the
sound software revision, revision level of the system software and date the game software was
revised.
Example:
PARTY ZONE
20004
Rev. L-1
Sound Rev. L-1
Sy.0.90
6/1/91
Press the Enter button to enter the WPC Menu System (refer to the section entitled 'Menu
System Operation' for more information). Perform the entire Test Menu routine to verify the
game is operating satisfactorily. Successful completion of the tests in the Test Menu routine
will show the game is ready to begin earning your investment return.
ATTRACT MODE·.
After completinp the Test Menu routine, press the Escape button
three times to enter the Attract Mode. During the Attract Mode, playfield and backbox lamps
blink. The display exhibits a series of messages informing the player concerning:
A. Recent highest scores"
B. A "custom message"
C. The score to achieve to obtain a Replay award"
These (or similar) displays reappear occasionally, accompanied by sounds and music, until a
player initiates game play by inserting a coin, or when credits are available, pressing the Start
button.
CREDIT POSTING.
Insert coin(s). A sound is heard for each coin. The display will show
the number of credits purchased. So long as the number of maximum allowable credits" are
NOT exceeded by coin purchase or high score, credits are posted correctly .
.•- Operator-adjustable feature.
PARTY ZONE 1-5
