6. Extend each leg leveler slightly below the leg bottom, so that all four foot pads are extended
about the same distance. Remove the cabinet from its support and place it on the floor.
7. Unlock and open the coin door. Locate the Molding Latch Lever, and move the lever toward
the left side of the game, to release the Front Molding. Lift the Front Molding off the playfield
cover glass return the Latch Lever toward the right, and close the coin door. Carefully slide the
glass downward, until it clears the grooves of the Left and Right Side Moldings. Lift the glass
up and away from the game, storing it carefully to avoid breakage.
8. Place a level or an inclinometer on the playfield surface. Adjust the leg levelers for proper
playfield level (side-to-side) and playfield pitch angle (incline) of approximately 6-7 degrees.
NOTE: It is recommended that these measurements be made ON the playfield, not the cabinet
nor the playfield cover glass. Tighten the nut on each leg leveler shaft to maintain this setting.
Playfield pitch angle adjustments can affect the operation of the plumb bob tilt, inside the
cabinet. The plumb bob weight is among the parts in the cash box; the operator should install
the weight and adjust this tilt mechanism for proper operation, after completion of the desired
playfield pitch angle setting.
9. Move the game into the desired location; recheck the level and pitch angle of the playfield.
10. Verify that the
required number
of balls are installed in the game.
PARTY ZONE
uses 3
balls.
11. Install playfield mylars if desired.
NOTE:
The
Party
Zone Diamond Plate™ playfield does not require a'~rotective mylar.
However, playfield mylars can be purchased thru your local Bally Distributor. Specify part
number 03-7960-20004-1 for full playfield mylar.
12. Clean and reinstall the playfield cover glass, reversing the procedure of step 7. Prepare the
game for player operation.
PARTY ZONE 1-3
