PINBALL GAME ASSEMBLY INSTRUCTIONS
PARTY ZONE IS A 3 BALL GAME.
1. Remove all cartons and parts from the shipping container, and set them aside.
2. Place the cabinet on a support and attach rear legs using leg bolts. Leg levelers and leg bolts
are provided among the parts in the cash box.
3. Attach the front legs (after installing leg levelers), using leg bolts See diagram below ..
F> -
I
I
I
I
I
I
.••.•.••.• ,
I
I..........
,
I
I.....
\
I;.....
........
I "."/
,,"
( .....rJ..--,.6:!-----1
I
I
I »<
I
, I .••.•
....~f.....
I
---------_1
Detail View-
Leg Leveler
..
,
,
\
See Detail View :
I
-,
"
..
_,
C-I0843-1
Leg
08-7377
Leg Leveler
I~
Nut
4422-01117-00
Pinball
Assembly,
Playfield Pitch Angle, and Leg Leveler Details.
4. Reach into the cabinet and backbox and ensure that the interconnecting cables are free to
move (not kinked or pinched). Be careful to avoid damaging wires at any stage of the assembly
process.
5. Raise the hinged backbox upright and latch it into position. Unlock the backbox, and remove
the backglass, storing it carefully to avoid scratches. Remove the shipping block holding the
Insert Board. Unlatch and open the Insert Board. This allows access to the bolt holes used for
securing the backbox upright. Install the washer-head mounting bolts through the bottom
holes of the backbox into the threaded fasteners in the cabinet to secure the backbox. Close
the Insert Board and latch it in position. Reinstall the backglass, and lock the backbox.
&'CAUTION
FAILURE
TO
INSTALL
the backbox mounting hardware properly can cause personal
injury.
NEVER TRANSPORT
a pinball game with the hinged backbox erect. Always lower the
backbox forward onto the playfield cabinet on a layer of protective material to prevent marring or
damage and possible personal injury.
PARTY ZONE 1-2
