6. Extend each leg leveler
slightly
belowthe legbottom, so that all four footpads are extended about
the same distance. Removethe cabinet from its support and place it on the floor.
7. Unlock and open the coin door. Locate the MoldingLatch Lever, and move the lever toward the
left side of the game, to release the Front Molding. Lift the Front Molding off the playfield cover
glass return the Latch Lever toward the right, and close the coin door.
Carefully
slide the glass
downward, until it clears the grooves of the Left and Right Side Moldings. Lift the glass up and
away from the game, storing it carefully to avoid breakage.
8. Place a level or an inclinometer on the playfield surface. Adjust the leg levelers for proper
playfield level (side-to-side)
m1:d.
playfield pitch angle (incline) of approximately 6-7 degrees.
NOTE: It is recommended that these measurements be made ON the playfield, not the cabinet nor
the playfield cover glass. Tighten the nut on each leg leveler shaft to maintain this setting, as
shown in Figure 3.
9. Movethe game into the desired location;recheck the level and pitch angle of the playfield.
CAUJ'l1'nOM
Playfield pitch angle adjustments can affect the operation of the plumb bob tilt, inside the cabinet.
The plumb bob weight is among the parts in the cash box;the operator should install the weight and
adjust this tilt mechanism for proper operation, after completion of the desired playfield pitch
angle setting.
10. Verifythat the
required number
of balls are installed in the game. THE MACHINE uses 3
balls.
11. Install playfield mylars if desired.
12. Clean and reinstall the playfield cover glass, reversing the procedure of step 7. Prepare the
game for player operation.
