GAME CONTROL LOCATIONS
Cabinet Switdles
The On-Off switcb is on the bottom of the cabinet near the right front leg.
The Start Button is a pushbutton to the left of the coin door on the cabinet exterior. Press the Start
button to begin a game, or during the diagnostic mode, to ask for HELP.
Coin Door Switches
The operator controls all game adjustments, obtains bookkeeping information, and diagnoses
problems, using only four pushbutton switches mounted on the inside of the coin door. The Coin
Door Switches have two modes of operation Normal Function and Test Function.
Normal Function
The Service Credits switch places credits on the game that are not included in the game audits.
The Volume Up switch raises the sound level of the game. Press and hold the button until the
desired level is reached.
The volume Down switch lowers the sound level of the game. Press and hold the button until the
desired level is reached. See Adjustment Al 28to shut sound Offcompletely.
The BeiPn Test switch starts the Menu System Operation and changes the Coin Door Switches from
Normal Function to Test Function.
Test Function
The Escape switch allows you to get out of a menu selection or return to the Attract Mode.
The
Ill2
switch allows you to cycle forward through the menu selections or adjustment choices.
The ~ switch allows you to cycle backward through the menu selections or adjustment choices.
The
E.n.tm:
switch allows you to get into a menu selection or lock in an adjustment choice.
Coin Door Switches
Figure
2. Pinball Game Controls Locations
