10. Move the game into the desired location; recheck the level and pitch angle of the playfield.
11. Verify that the required number of balls are installed in the game.
The Getaway
uses 3 balls.
12. Install playfield mylars if desired.
Note:
The
The Getaway
playfield is coated with a covering called Diamond Plate™ and does not
require a protective mylar. However. mylars can be purchased through your local Williams
Distributor.
Specify part number 03-8661-1 for full playfield mylar.
13. Clean and reinstall the playfield cover glass. Prepare the game for player operation.
Control Locations
Cabinet Switches
The On-OfTSwitch is on the bottom of the cabinet near the right front leg.
The Start Button is a pushbutton to the left of the coin door on the cabinet exterior. Press the
Start button to begin a game. or during the diagnostic mode. to ask for HELP.
Coin Door Switches
The operator controls all game adjustments.
obtains bookkeeping information. and diagnoses
problems. using only four pushbutton switches mounted on the inside of the coin door. The Coin
Door Switches have two modes of operation Normal Function and Test Function.
Normal Function
The Service Credits Switch puts credits on the game that are not included in the game audits.
The Volume
Up
Switch raises the sound level of the game. Press and hold the button until the
desired level is reached.
The Volume Down Switch lowers the sound level of the game. Press and hold the button until the
desired level is reached. See Adjustment
Al
28 to shut sound OfTcompletely.
The Begin Test Switch starts the Menu System Operation and changes the Coin Door Switches
from Normal Function to Test Function.
Test Function
The Escape Switch allows you to get out of a menu selection or return to the Attract Mode.
The Up Switch allows you to cycle forward through the menu selections or adjustment choices.
The Down Switch allows you to cycle backward through the menu selections or adjustment
choices.
The Enter Switch allows you to get into a menu selection or lock in an adjustment choice.
Holding the Enter button for 5 seconds. during the Attract Mode. resets the High Scores.
Coin Door Switch Locations
The
Getaway 1-4
