STANDUP TARGET
Standup Target (Blue)
Standup Target (Green)
Stand up Target (Red)
Standup Target Assemblies
(Including Diode)
Item Part No.
8-11696-1
8-11696-2
8-11696-4
01-8652
BRACKET
~
A-8645
SWWlRE
&
BRKT
5070~258-OO ---""
DIODE
5647-12073-01
MICROSWITCH
-------E~~==~
MOUNTING PlATE
RM-21-Q3
TUBING
564Hl9957-00 --_../
MICROSWITCH
BALL TROUGH SWITCHES
Ball Trough Switches
Part No.
Description
8-11348
A-5844-44
8-11349
RM-21-03
4004-01060-08
4005-01005-02
5070-06258-00
5647-09957-00
5825-09373-00
A-11680
01-8652
5647-12073-08
5070-06258-00
A-8645
Sw~ch Plate Assembly
Sw~ch Wire & Bracket Assy
Sw~ch Mount
Plate Sub-Assy
#10 Tubing
MS 4-40 x 1/2 SL-PH-S
MS 5-40 x 1/8 P-PH
Doide, 1N4001, 1A
IlSwitch E21-50H
#4 Solder Lug-bent
Ball Trough Switch, Right
Mounting Bracket
Submin. Switch
Diode, 1N4001, 1.0A
Sw~ch Wire & Bracket Assy
Ball Trough
&
Stand-up Target 2-15
