50069-8B
Back Box Assembly
Item Part Number Description
Item Part Number Description
1 04-12754
Back Box
15
24-8809
Fluorescent lamp
2 A-22982
Back Boor Assembly
15W, 18-
3 01-15131
Door Channel
16 04-12752
Ballast Mounting Bracket
4 03-9992
Knob
17 A-23155
Ballast Assembly
5 A-22981
Lock
&
Plate Assembly
18 A-23160
CPU/AC Power Cable
6 01-15134
Front Lock Cam
19 H-22737-1.1 AC/Speaker Cable
7 A-22975-50069 Marquee Assembly
20 20-10581
Extension Cable
8 04-12607.1 Speaker Grill Bracket
db09-6ft
9 04-12606.1 Speaker Grill
21 20-10580
Extension Cable
10 5555-16223-00 Speaker - ~, 25W
db25-6ft
11 5675-16058-02 Monitor -19-
12 01-15130.2 Computer Case Mounting
Miscellaneous Parts:
Bracket
Hem Part Number Description
13 A-22724
Computer Case Assembly
22 11-1464
Back Box Shipping Brace
14 A·22980
Fluorescent Lamp
23 5556-16449-00 Ferrite
Assembly
*24 02-4352-3
Pivot Bushing
*25 4322-10228-12 CS 3/8-16 x
%
Button
Head - Nylon Patch
*26 47C»OO111-DOFW .390 x .875 x .062
2-4
