SOO69-CAB
Cabinet Assembly Parts List
Item PartNumber
Description
1 04-12753.2
Cabinet
2 01-11400-1
LegMountingBracket(x4)
3 04-12869
LegAssembly,Heavy-BlackRidge(x4)
4 08-7377
LegLeveler/Adjuster(x4)
5 01-15132-1
PlayfieldSlideTrack- Right
6 04-12610
StayArm
7 A-22996
LockdownBracketAssembly
8 A-23419
Speaker
&
CableAssembly
9 A-22966
PowerControlBoxAssembly
10 04-12596.1
DripPlate
11 5610-15930-01
TransformerAssembly
12 A-22998
DriverBoardCoverAssembly
13 A-23299
DriverBoardBackPlateAssembly
14 04-12329
PowerDriverBoard
15 03-10011
CoverStopTube
16 09-96032-33
CoinDoor- USA- 2 Slot
17 20-10690
HandMoldingLock
18 A-22984-1
FlipperButtonAssembly(x2)
19 20-10696
PushButtonw/Switch-
START
(yellow)
20 01-3535
BallShooterMountingBracket
21 A-17730-1
BallShooterAssembly
22 A-23024
CoinDoorInterlockSwitchAssembly
23 A·229M
CoindoorInterfacePCBAssembly
&
Spacer
24 A-17195-2
Tilt SwitchAssemblyw/Cable
25 04-10346.1
TiltMechanismAssembly
26 2O-6502-A
PlumbBob
27 A·23139
4-BaIICashBoxAssembly
28 A·22997
HandMoldingAssembly
29 A·22976-1
SideMoldingAssembly(x2)
30 04-12739.1
TintedPlayfieldGlassAssembly
31 03-8091
RearMolding
32 01·15214
HoleCover
33 01-15212
CabinetCornerBracket
34 01-14085.1
HaspHingeBracket
35 01-14086.1
HaspStapleBracket
36 20-10704-1
SlitHoseSleeve- &1.25x 60·Lg.
37 A·23421
JoinedCableAssembly
cabinet cables:
38 H-2274Q.3
39 H·22740-1.2
4Cr* H·23412
41 H-23420
42** 20-10581
43** 20-10580
CabinetCable
CabinetCable
Isolation/SpeakerCable
CabinetSwitch/LampCable
ExtensionCable,db25- 6ft
ExtensionCable,db09- 6ft
Miscellaneous
Parts:(NotShown)
PartNumber
Description
01·15132-2
PlayfieldSlideTrack- Left
04-12628.2
SafetyBracket
01-15136-1-2
LockPlate
*
Cordset
20-6500
SteelBall,
&1-1/16"
(x4)
01-6389-1
CashBoxlockBracket
01-12352
ClipBracket
4322-1125-40
3/8x 16HexAcornHeadLegBolt
01-14084.2
SlottedHaspPlate
A-23297
UniquepartsBag- 50069
•See
Power InterlacelCordsst Application Chart
on
page 2-31
•• Th9se cables are shown for reference only. They
are
part of Item37, A-23421, JoinBd Cable Assembly.
2-3
