GAME CONTROL LOCATIONS
Cabinet Switches
The ON/OFF SWITCH is on the bottom of the cabinet on the middle of the right side.
The START BUTTON is a push-button to the left of the coin door on the cabinet exterior. Press the Start
button to begin a game, or during the diagnostic mode, to ask for HELP.
Service Lock
The service lock allows the operator to gain access to the playfield without allowing access to the cash
box. With the coin door closed, turn the key in the service lock and the front molding pops up. Remove
the molding and slide the glass down and off of the cabinet. The operator can clean the playfield or
remove a trapped ball without being able to lift the playfield and gain access to the cash box.
Coin Door Buttons
The operator controls all game adjustments, obtains bookkeeping information, and diagnoses problems,
using only four push-button switches mounted on the inside of the coin door. The coin door buttons have
two modes of operation Normal Function and Test Function.
NORMAL FUNCTION
The SERVICE CREDITS button puts credits on the games that are not included in any of the game
audits.
The VOLUME UP
(+)
button raises the sound level of the game. Press and hold the button until the
desired level is reached.
The VOLUME DOWN (-) button lowers the sound level of the game. Press and hold the button until
the desired level is reached. See the Adjustment menu to turn the sound down all the way.
The **BEGIN TEST button starts the Menu System operation and changes the coin door buttons from
Normal Function to Test Function.
TEST FUNCTION
The ESCAPE button allows you to get out of a menu selection or return to the Attract mode.
The UP
(+)
button allows you to cycle forward through the menu selections or adjustment choices.
The DOWN (-) button allows you to cycle backward through the menu selections or adjustment
choices.
The ENTER button allows you to get into a menu selection or lock in an adjustment choice.
Coin Door Buttons
Service Lock
Front Molding
*Lever
Flipper Button Assembly
~ On/Off Switch
(under cabinet)
Ball Shooter
The START BUTTON is not shown on this drawing. It is located below the service lock.
*The LEVER is part of the LOCK BRACKET ASSEMBLY.
** To Reset the High Scores, press and hold the Begin Test button.
