RAISING THE PLAYFIELD
&
CAUTION
This game uses playfield support assemblies to raise and lower the playfield. Be sure the back of
the playfield supports slide along the cabinet tracks until the feet hook into the loop at the end of
the track.
Before Raising the Playfield:
Be sure there are no balls present in any of the ball-holding playfield devices (i.e. poppers).
Raising the playfield with balls present in these locations may cause them to come loose and
damage the playfield. Use the "Empty Balls Test" to remove all of the balls from these locations.
To Raise the Playfield:
1. Open the coin door. Remove the front
molding and the playfield glass. Lift the
playfield by the metal bracket under the front
of the bottom arch. Rest it on the top of the
cabinet, nesting the plastic hex button in the
trough of the bracket.
2. Close the coin door. Grasp the playfield by
the supports and pull it toward you along the
track slides until it stops. Rotate the front of
the playfield up and back toward the
backbox.
To Lower the Playfield
1. Rotate the front of the playfield down and
push it back, away from you, along the track
slides. Rest it on top of the cabinet. Open
the coin door.
2. Grasp the playfield by the metal bracket
under the front of the bottom arch and lower
it back into the cabinet.
Replace the
playfield glass and the front molding. Close
and lock the coindoor.
Slide the Feet of the
Playfield Along the Tracks.
Be Sure the Feet of the
Playfield Hook into the
I..oOpon the Tracks.
1-9
