XI. PARTS LIST
#1157 SILVERBALL MANIA
MISCELLANEOUS
PART NUMBER
Transformer (Domestic or Export)
E-122-125
Bulbs, #44
E-125-22
Fuse,1 Amp.3 AG Slow Blow (Playfield Solenoid Protection)
E-133-44
ASSEMBLY COILS
Coin Lockout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. .
FO-36-7000
Flipper (2)
AQ-25-S00/
34-4500
Knocker
AR-26-1200
Outhole Kicker
AN-26-1200
Thumper-Bumper (3)
AN-26-1200
Sling-Shot (2)
AN-26-1200
Up Kicker
.
NO-26-1900
Down Kicker
AN-26-1200
PLAYFIELD PARTS
See Figure II
MODULES
Lamp Driver AS
AS-2518-23
Display Driver A1 (5 used)
AS-2518-21
Solenoid Driver/Voltage Regulator A3
AS-2S18-22
MPU A4
AS-2962-13
Transformer & Rectifier A2
AS-2877-1
Rectifier Board (Part of A2)
AS-2518-18
Sound
AS-3022-3
REPAIRS PROCEDURES! AIDS
Module & Component Replacement
F.O.S60-1
AID (Assistance in Diagnostics)
Kit, used with F.O.S60-1
KIT #485-1
MODULE COMPONENTS
SEE~ODULE PARTS LIST
MODULE COMPONENT STARTER KITS
(Eac h Kit contai ns an assortm ent of the most needed electro nic parts for use in ModuIe repai r.)
Kit #490-For Rectifier Board (Part of A2)
Kit #503- For MPU Board A4 (Less Memory U1-U6)
Kit #492-For Solenoid Driver/Voltage Regulator A3
Kit #493-For Display Driver A1
Kit #494-For Lamp Driver AS
Kit #S59-For Sound A8
