ASSEMBLY ADJUSTMENTS:
GENERAL:
All switch assemblies consist of leaf springs, contacts, separators, plastic tubing and screws
to hold them to the mounting surface -,Before attempting to adjust a switch assembly, make
sure that these screws are tight. If not, tighten screw closest to the contact end of the leaf
spring first. This will prevent the assembly from being secured in such a manner that the leaf
springs tend to fan out. In general, all leaf springs are adjusted for a
1/16"
gap in the open
position and .010" overtravel or wipe in the closed position. All contacts should be in good
condition. Unless otherwise instructed, they should be dry or non-lubricated. All contacts
should be free of dust and dirt. Contacts, with the exception of the flipper button switch
assemblies, are plated to resist corrosion. Filing or burnishing breaks the finish and encour-
ages corrosion. Clean by closing the contacts over a clean piece of paper (e.g. a business
card) and wiping gently until the contacts are clean. For the flipper button switch assemblies
ONLY: Tarnish can be removed with a contact file followed by a burnishing tool. Severely
pitted contacts must be replaced as an assembly. In general, contacts need be cleaned or
replaced and adjusted only when they are found to be a source of game malfunction.
X. SERVICE PARTS:
A
parts catalogue is available upon request. The catalogue is illustrated and lists all replace-
ment parts tor each game manufactured by Bally. Requests shoulc be addressed to:
BALLY MANUFACTURING CORPORATION
2640 WEST BELMONT AVENUE
CHICAGO, ILLINOIS 60618
ATTN: PARTS DEPARTMENT
SERVICE HINTS:
The Bally playfield has an Improved tuff-coat finish with excellent wearing properties. Its life
expectance, as well as play appeal, can be extended by periodic cleaning of the playfield.
DO: Bally recommends you clean
your
playfield with Wildcat #125 (Wildcat Chemical Co.,
1333 W. Seminary Drive, Ft. Worth, Texas 76115). Wildcat #125 is a combination cleaner and
polish. Bally has tried and tested this product and found it to be very effective. If Wildcat #125
is not ava
i
Iable, Sa Ily suggests you
ask
you r 0 istri buto r to order it. Inspect and hand po Iish the
ball in a clean cloth. A chipped ball must be replaced. It can ruin the finish on the playfield in a
short period of time.
DON'T: Use water in large quantities, highly caustic cleaners, abrasive cleaners or cleaning
pads on the playfield.
00
not allow a wax or polish build up. Waxes yellow with age and spoil
play appeal.
