#1157 SILVERBALL MANIA
RUBBER PARTS
A R-521-1
1" Dia.
(3)
B R-521-2
1112"
Dia.
(2)
C R-521-3
2" Dia.
(1)
D R-521-4
2112"
Dia.
(4)
E R-406-3
Flipper
(2)
F R-243
5/16" Dia. (14)
PANEL TOP PARTS
1 Arch Rail
M-1774
2 Rail Post
C-907
3 Rail Post Cap
C-908
4 Bottom Arch
P-5871-72
5 Shooter Gauge
P-6359-38
6 Ball Rebound Assy.
AS-493-6
7 Ball Gate Assy.
A-1475-13
8 Screened Plastic Set
M-1330-159
9 Bumper Cap
A-3852-1 (4)
10 Thumper Bumper Cap A-3713-58 (3)
11 Ball Guide Wire
M-121-32 (6)
12 Roll Over Wire Assy.
AS-2806 (7)
13 Target Assy. (yellow)
AS-2911-21 (11)
14 Ball Guide Wire
M-121-30
15 Ball Gate
&
Wire
AS-2250-24
16 Spinner Gate Assy.
AS-2250-61
17 Spinner Gate Assy.
AS-2250-62
18 Ball Guide Assy.
A-3032-34
0000
19 Ball Guide Wire
M-121-24 (2)
20 Ball Guide Wire
M-121-78
0000000000
21 Ball Guide Wire
M-121-79
22 Disappearing
AS-3007
Kicker Assy.
23 Ball Guide Wire
M-121-91
24 Ball Guide Wire
M-121-92
25 Flipper
&
Shaft Assy.
AS-2214-24 (2)
26 Mini-Post Assy.
AS-2836-1 (8)
0
LIB. -liberal
MED. -Medium
CONS.-Conservative
Indicates Movable Posts
For Spring Adjustments.
9
