A-20911
Spin Target Assembly
®
I
,-
,./
-:
~
(,/
~~
~g
I
Item Part Number
Description
Item Part Number
Description
1 04-10410
Spin Bracket
10 4110-01013-08 SMS #10-32 x 1/2 P-PH T25 (3)
2 03-9126
Spinning Disc
11 4700-00016-00 FW .187 x .437 x .053 (3)
3 31-2556
Decal
12 03-8247-13
Post #8 Double Star, Clear
4 04-10412
Adjust Screw Assembly
13 23-6300
Rubber Ring 5/8", White (2)
5 A-20952
Spin Disc Cpto PCB Ass'y
14 4408-01119-00 Nut #8-32 ESN
6 03-8363-1
Locking Nut
15 4008-01 003-04 MS 8-32 x 1/4 P-PH-S
7 03-8347
Gland
16 4006-01 003-04 MS 6-32 x 1/4 P-PH-S (3)
8 02-4418
Shaft
17 4008-01041-10 MS 8-32 x 5/8 P-FH
9 4108-01013-08 SMS #8-32 x 1/2 P-PH T25 (3)
18 4008-01113-28 MS 8-32 x 1-3/4 PL-HWH
2-23
