Section 1
GOmil'!e
WI
,~, i~ ..
Operation
g;_
Qt
Test
Information
• ROlLERGAMES
(System 11C) ROM Summary
• Pinball Game Assembly Instructions
• Game Play
• Game Status Displays
• Game Adjustment Procedure
• Game Pricing
• Test/Diagnostic Procedures
RO:LlERGAMES (System 11C) ROM Summary
IC
DESCRIPTION TYPE IDENTIFIER BOARD PART NUMBER
Game ROM 1
32K x 8 ROM 27256 U27
CPU A-5343-576-2
Game ROM 2
32K x 8 ROM 27256 U26
CPU A-5343-576-1
Music/Speech ROM 1 64K x 8 ROM 27512 U4
Audio A-5343-576-3
Music/Speech ROM 2 64K x 8 ROM 27512 U19
Audio A-5343-576-4
Music/Speech ROM 3 64K x 8 ROM 27512 U20A
Audio A-5343-576-5
NOTICE
To order a replacement ROM from your authorized WILLIAMS ELECTRONICS GAMES
distributor, specify: (1) part number (if available); (2) ROM label color; (3) ROM level (num-
ber) on the label; (4) which game the ROM is used in.
ROL.L.ERGAMES 1
'.
