locations
Diagram.
Game Circuit Boards and Major Mechanisms
Under Side of Playfield,
Viewed in Raised Position
LOCATIONS
Gil
Circuit Boards
II
Lamp Boards
o
Major Mechanisms
Backbox
Display/Speaker Panel, Rear View
Rly
Bel
rn
Sol. 10
Insert Board, Inner Side View
B-8039-2
Outhole Kicker (under Btm Arch)
C-11223-1
3-Bank Drop Target
C-11626-L -3
Lower Left Flipper
C-13205
3-Bank Opto Board
-,
C-11626-R-3
Lower Right Flipper
C-11998-1
Relay Board (Sol. 11 Gen. ilium)
C-9638
Shooter Lane Feeder
B-9414-1
Jet Bumper (3 total)
B-9362-L-l
Coil & Bracket Assembly
B-9415-1
Bumper Coil & Bracket Assembly (3)
B-12224
lamp Board ("1")
C-12709
Lamp Board ("3-L")
C-13374
Lamp Board ("20
+
3 x "F")
C-12000
Lamp Board ("3- T")
C-13375
lamp Board (OF")
B-12665
Left & Right Kicker Arm Assembly
B-1 0686-1
Knocker Assembly
B-9362-R-1 Coil & Bracket Assembly
D-11581-576
Audio Board
B-9362-L-1 Coil & Bracket Assembly
0-12246
Power Supply Board
C-13361
lamp Board ("3-R")
0-11883-576
System 11C CPU Board
C-13362
lamp Board ("5-L")
0-12247-576
Aux Power Driver Board
C-13425
lamp Board ("3-C")
0-12313-576
Backbox Int9rcOnnect Board
B-13496
lock Diverter Assembly
B-13494
Diverter Arm & Shaft Assembly
0-13536
Spkr/Oisplay/lamp Panel Assembly
C-13509
High Current Driver Assembly
C-13537
Lamp Board ("8-D")
B-13520
Magnet Assembly
D-12232-1
Master Display Board
C-13723
Upper Right Flipper
C-11998-1
Relay Board (Sol. 10 Gen. ilium)
ROLLERGAMES 42
