Circuit/Location
Fuse Listing
Fuse Locations Diagram
&
Listing
11- .-..-.
ITO
Description
Fuse, 3/8A., Slow-Blow (S-B), 250V
Fuse, 1/8A., S-B, 250V
Fuse, 7A S-B, 250v
Fuse, 2-1/2A., S-B, 250v
Fuse, 5A., S-B, 250v
Fuse, 2A., S-B, 250v
Fuse, 4A., S-B, 250v
Fuse, 7A., S-B, 250v
Fuse, 8A., Normal-Blow (N-B), 32v
Fuse, 5A., S-B, 250v
Fuse, 5A., S-B, 250v
Fuse, 8A., N-B, 125v
F1; 0-12246 Power Supply Board
F2, F3; 0-12246 Power Supply Board
F4, F5; 0-12246 Power Supply Board
F2A, F3, F4; 0-12247 Aux Pwr Driver Board
F1, F2C; 0-12247 Aux Pwr Driver Board
F5, F6; D-12247 Aux Pwr Driver Board
F7; D-12247 Aux Pwr Driver Board
F8; 0-12247 Aux Pwr Driver Board
+18 Vdc Lamp Cktl Lwr Rt B'box fuseholder (1)
F1 - F4: Gen. l1IuminlB'box Interconnect Board
F1; C-13088 Triac Assembly Board
Input ("high voltage") Power Line/Cabinet Box"
-,
Item Part Number
1
1
1
2
2
2
2
2
3
4
5
5731-12328-00
5731-12327-00
5731-09432-00
5731-09128-00
5731-09651-00
5731-08665-00
5731-06314-00
5731-09432-00
5730-09071-00
5731-09651-00
5731-09651-00
5730-09252-00
• One 4A., S-B, 250v fuse (5731-06314-00) is provided for an overseas (220v) game installation.
Concerning the fuses listed as item 2, F1 protects the +25V de Special Solenoid circuit connected via the Red-
White wires, including the Left, Right, and Lower Jet Bumpers for ROLLERGAMES.
F2A protects the "A"
Solenoids connected with Brown wires, including the Outhold Kicker, Shooter Lane Feeder, and the Lock Diverter.
F2C protects the "C" Solenoids connected with Orange wires, including Flash
t,
through Flash 8 circuits. F3
protects the Controlled Solenoids connected with Red wires, including Flash 9, lnsert 'Bd Gen~ral Illumination
Relay, Playfield General Illumination Relay, and the Left and Right Kickers. F4 protects the +50V Solenoids
connected with Violet-Yellow wires, including Upper Kickback, Lock Kickback, Ramp Oiverter, Outlane Kickback,
and the Deep Freeze Magnet. F5 protects the Lower and Upper Right Flippers. F6 protects the Lower Left Flipper.
F7 protects the input to the +50V dc rectifier, and FB protects the input to the +25V de rectifier on the Aux Power
Driver Board.
ROLlERGAMES 40
